Description
These arms eliminate upper ball joints w/ super strong 1” ID Stainless American Uniballs. Additional caster is built into Arms for greater align ability to help with problematic leveling kit alignments. Allows for increased wheel travel when used with Dirt Logic 2.5 Stainless Steel Coilover shocks. Chromoly tubing reduces flex found in stock arms for more positive road feel. 4340 Heat treated Uniball pin fits into factory ball joint taper without modification to the spindle for easy return to stock feature. Arms are direct replacements for factory arms on suspensions that require additional strength and align ability. Material Construction Specs. Built with same materials as found on Trophy Trucks. .120” Wall 4130 Chromoly Tubing. 1.25” OD. .250” wall DOM Bushing Barrels. 1” ID Stainless Steel American Uniball. 17-4 Stainless Misalignments. Heat Treated 4340 Tapered Uniball Pins. Includes rear 2.25 Dirt Logic Stainless Steel resivior shocks.
Specifications:
| California Proposition 65 | WARNING: Cancer & Reproductive Harm and image |
| Title | Fabtech 3″ UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 2010-13 TOYOTA FJ 4WD |
| Description_ASC | TIRE SIZE – 33/12.50R17 WHEEL – 17X8 W/4 5/8″ BS W/MINOR TRIMMING; TIRE SIZE – 275/60R20 WHEEL – 20X9 W/5″ BS W/MINOR TRIMMING; TIRE SIZE – 275/70R18 WHEEL – 18X9 W/4 3/4″ BS W/MINOR TRIMMING |
| Description_DEF | Suspension Lift Kit |
| Description_DES | 3″ UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 2010-13 TOYOTA FJ 4WD |
| Description_EXT | 3″ UCA & DLSS 2.5 C/O SYS W/ DLSS RESI RR SHKS 2010-13 TOYOTA FJ 4WD. |
| Description_INV | Fabtech-3″ UCA & DLSS 2.5 C/ |
| Description_MKT | These arms eliminate upper ball joints w/ super strong 1” ID Stainless American Uniballs. Additional caster is built into Arms for greater align ability to help with problematic leveling kit alignments. Allows for increased wheel travel when used with Dirt Logic 2.5 Stainless Steel Coilover shocks. Chromoly tubing reduces flex found in stock arms for more positive road feel. 4340 Heat treated Uniball pin fits into factory ball joint taper without modification to the spindle for easy return to stock feature. Arms are direct replacements for factory arms on suspensions that require additional strength and align ability. Material Construction Specs. Built with same materials as found on Trophy Trucks. .120” Wall 4130 Chromoly Tubing. 1.25” OD. .250” wall DOM Bushing Barrels. 1” ID Stainless Steel American Uniball. 17-4 Stainless Misalignments. Heat Treated 4340 Tapered Uniball Pins. Includes rear 2.25 Dirt Logic Stainless Steel resivior shocks. |
| Description_SHO | 3″ UCA & DLSS 2.5 C/ |
